85Ω SAS 5.0 Cable – High-Speed Internal Data Transmission Cable

Product Description

The 85Ω SAS 5.0 Cable is engineered for high-speed internal data transmission applications, supporting speeds up to 24Gbps. Constructed with silver-plated copper conductors, FEP/PP insulation, and tinned copper drain wire, this cable ensures reliable signal integrity and low attenuation in data-intensive environments. It is ideal for connecting storage devices in data centers, servers, and enterprise-level computing systems.

Key Features

Impedance: 85 Ohms – optimized for SAS 5.0 protocol

Data Rate: Supports up to 24Gbps high-speed transmission

Conductor Material: Silver Plated Copper – superior conductivity and corrosion resistance

Insulation Material: FEP/PP – excellent dielectric properties and thermal stability

Drain Wire: Tinned Copper – effective EMI shielding

Rated Voltage: 30V

Rated Temperature: 80°C

Flame Rating: VW-1 (flame-retardant)

Certifications & Compliance

UL AWM Style 20744

Standard: UL758

File Number: E517287

Environment: RoHS 2.0 Compliant – environmentally friendly and lead-free

Applications

Internal High-Speed Data Transfer in enterprise servers and storage systems

SAS Interface Connections in data centers and cloud computing infrastructures

High-Performance Computing hardware and industrial data processing equipment

Internal Cabling for RAID Arrays, backplanes, and JBOD enclosures

Why Choose This SAS 5.0 Cable?

Optimized for the latest SAS 5.0 interface standard

Ensures minimal crosstalk and signal degradation

Flexible, durable, and reliable for mission-critical internal wiring
